Advanced Lithium-Ion Energy Solutions

Scalable, safe LFP batteries with smart BMS for high-performance power needs.

Technical Specifications

This high-capacity 25.6V LFP battery system is designed for scalable rack-mounted applications, offering 2.56 kWh of reliable energy storage.

  • Optimized with 25.6V rated voltage and 100Ah capacity for stable power.
  • Utilizes high-efficiency 3.2V 100Ah LFP cells for long-term durability.
  • Supports a maximum discharge current of 100A to handle high power loads.
  • Delivers over 3000 cycles at 90% depth of discharge for extended life.
  • Designed for standard 19-inch 4U racks with a robust powder-coated case.
  • Operates safely in temperatures from 0°C up to 55°C during discharge.
Compact Design

Compact Design

Fits standard 19-inch 4U racks with a durable powder-coated MS cabinet for indoor installation.

Thermal Safety

Thermal Safety

Integrated over- and under-temperature protection keeps the system safe during heavy operations.

Cell Longevity

Cell Longevity

Features internal cell balancing to ensure uniform voltage and maximize the overall cycle life.

Reliable Build

Reliable Build

Robust M8 wire lug terminals provide secure high-current connections for demanding power needs.

Applications and Use Cases

Perfect for modular telecommunication hubs and data centers requiring 19-inch rack integration. Its 2.56kWh scalability supports long-duration backup for critical network infrastructure and UPS.

Financial Capital

Financial Capital2

Financial Capital3

Financial Capital4

Learn More

Technical Specifications

A dedicated 12.8V 1.28 KWh lithium-ion solution engineered for inverter systems, providing a safer and lighter alternative to lead-acid batteries.

  • Rated at 12.8V with a 100Ah capacity using prismatic LFP cell chemistry.
  • Features a peak short-term current of 100A for two seconds for startups.
  • Equipped with an IP55-rated MS enclosure for superior indoor protection.
  • Provides broad communication via CAN, UART, RS485, and Bluetooth data.
  • Maintains performance across a discharge range of -20°C to 55°C safely.
  • Compact design weighing only 14kg for easy installation and handling.
Download Brochure
Smart Tracking

Smart Tracking

Comprehensive data logging via Bluetooth and RS485 enables seamless, real-time monitoring.

High IP Rating

High IP Rating

IP55-rated MS enclosure offers superior protection against dust and water for varied environments.

Dynamic Surge

Dynamic Surge

Supports a peak short-term current of 100A for two seconds to handle initial inverter startups.

Advanced Tech

Advanced Tech

Built with 100Ah prismatic LFP cells to deliver high energy density in a lightweight package.

Applications and Use Cases

Specifically engineered for residential and small office inverter systems. The IP55 enclosure and Bluetooth monitoring make it ideal for dependable home energy storage and off-grid solar setups.

Financial Capital

Financial Capital

Financial Capital

Financial Capital

Technical Specifications

This 12.8V 100Ah module focuses on precision and safety, featuring integrated protection and a compact form factor for versatile energy needs.

  • Delivers 1.28 kWh of energy with a reliable nominal 12.8V LFP platform.
  • Includes passive cell balancing to maintain individual cell health over time.
  • High-current capability with a 100A maximum discharge for various uses.
  • Operates safely within a precise voltage range from 14.2V down to 11.6V.
  • Features thermal protection that triggers between 65°C and 75°C limits.
  • Designed with M10 ring terminals for secure and easy power connections.
Safe Chemistry

Safe Chemistry

Utilizes stable Lithium Iron Phosphate chemistry to eliminate risks of thermal runaway events.

Passive Balance

Passive Balance

Employs precise passive cell balancing to maintain battery health without complex active needs.

Thermal Cutoff

Thermal Cutoff

Protective sensors trigger between 65°C and 75°C to prevent any heat-related internal damage.

Simple Hookup

Simple Hookup

Features M10 ring terminals for easy and reliable wiring into existing 12V electrical systems.

Applications and Use Cases

Versatile power source for marine, RV, and caravan auxiliary systems. Its thermal protection and high discharge capacity ensure safety for cabin lighting, trolling motors, and portable appliances.

Technical Specifications

Engineered for high-voltage industrial needs, this 73.6V module provides 7.36 kWh of power in a scalable 23-inch 4U rack-ready configuration.

  • High nominal voltage of 73.6V coupled with a large 100Ah storage capacity.
  • Integrated BMS provides accurate SOC calculations via current integration.
  • Advanced RS-485 and CAN ports allow for seamless inverter communication.
  • Stores up to 380 history messages for comprehensive performance tracking.
  • Robust 90kg unit built into a 4U rack structure for modular expansion.
  • Charges at 80.5V and maintains steady discharge down to 69V accurately.
Smart Analysis

Smart Analysis

Uses the current integration method for high-accuracy SOC calculation and life-cycle counting.

History Logs

History Logs

Internal memory stores 380 history messages, including protection times and voltage snapshots.

Precise Sensing

Precise Sensing

Detection accuracy within 5mV for cell voltage ensures the BMS manages every cell perfectly.

Dual Comms

Dual Comms

Supports both CAN for inverter communication and RS-485 for detailed operation control.

Applications and Use Cases

Designed for high-voltage industrial machinery and light electric mobility, such as forklifts or AGVs. The RS-485/CAN communication enables seamless integration with sophisticated motor controllers.

Technical Specifications

This 121.6V ultra-high-voltage module is designed for large-scale energy storage, offering a massive 12.16 kWh capacity in a single rack unit.

  • Powerful 121.6V-rated system designed for high-voltage energy modules.
  • Features a sophisticated 9-LED status indicator for real-time monitoring.
  • Scalable design allows master-slave pack power control via DIP switches.
  • Reliable LFP chemistry ensures over 3000 cycles in 25°C environments.
  • Includes high-precision cell voltage detection with a 15mV accuracy.
  • Heavy-duty MS metal cabinet weighs 130kg for maximum system stability.

Applications and Use Cases

Optimal for large-scale energy storage systems (ESS) and micro-grids. The 121.6V architecture is built for high-demand power plants requiring massive energy density and master-slave pack control.

Technical Specifications

A compact 691.2Wh battery module utilizing cylindrical LFP cells, designed for straightforward power applications requiring 54Ah capacity.

  • Provides 12.8V nominal power with 54Ah capacity for compact electronics.
  • Built using 3.2V 6Ah cylindrical cells for a robust modular internal.
  • Supports continuous charging and discharging at 10.8A for daily usage.
  • Maximum discharge current of 20A allows for moderate power bursts easily.
  • Wide operating temperature range supports discharge from 0°C to 55°C well.
  • Lightweight and simple design for integration into custom battery banks.
Cylindrical Cell

Cylindrical Cell

Built with 32700 cylindrical cells for a robust internal structure and consistent performance.

Stable Current

Stable Current

Supports a steady 10.8A continuous charge and discharge for reliable everyday power delivery.

Versatile Use

Versatile Use

Wide operating temperature range allows for efficient discharging even in 55°C environments.

Manual Setup

Manual Setup

Non-smart design offers a simplified interface for direct integration into custom power banks.

Applications and Use Cases

Reliable energy solution for electric street lighting and automated security systems. The cylindrical cell design provides a steady power supply for remote monitoring stations and outdoor equipment.

Technical Specifications

This 307.2Wh module offers a portable energy solution with 24Ah of capacity, balancing power and size for non-smart energy requirements.

  • Nominal 12.8V output with 24Ah capacity using cylindrical cell builds.
  • Efficient charging at a nominal 4.8A to preserve long-term cell health.
  • Peak discharge capability of up to 20A for versatile application use.
  • Maintains a safe operating voltage window between 14.2V and 10V daily.
  • Uses 3.2V 6Ah cells as the primary building blocks for the 24Ah module.
  • Small footprint design specifically tailored for space-constrained sites.
Slim Profile

Slim Profile

Extremely compact footprint makes it ideal for space-constrained portable power applications.

Balanced Charge

Balanced Charge

Optimized for 4.8A charging to ensure the 24Ah capacity remains healthy over many cycles.

Burst Support

Burst Support

Capable of handling 20A maximum discharge current for short periods of increased power demand.

Standard Safety

Standard Safety

Provides essential protection for discharging down to 10V to prevent over-depleting the cells.

Applications and Use Cases

Highly portable for medical equipment, portable testing tools, and small-scale robotics. Its compact footprint allows it to fit into tight spaces while providing a robust 307.2Wh of mobile energy.
